Synthetic Fiber Pocket Filters Bag Air Filter F6 F7 F8 F9 with High Dust Capacity for HVAC AC System
Synthetic Fiber Pocket Filters Bag Air Filter F6 F7 F8 F9 with High Dust Capacity for HVAC AC System
Features
The pocket is made of a high-strength fiberglass fiber material that is bonded to a thin synthetic backing and sewn with multiple rows of extended stitching. These filters, which offer medium to high efficiency, are suitable for various commercial and industrial applications as well.
- Versatile Compatibility: Compatible with a wide range of HVAC and AC systems, offering flexibility in installation.
- Low Air Resistance: Maintains optimal airflow while effectively filtering out impurities, promoting energy efficiency.
- Cost-Effective Solution: Helps prolong the lifespan of your HVAC system by preventing dust buildup, reducing the need for frequent maintenance or repairs.
Fast Sampling Support
Samples ready within 3–7 days for custom OEM & ODM orders. Flexible customization solutions are available to match your unique product requirements.
Advanced Production Equipment & Stable Quality
Equipped with professional automated production lines and sophisticated testing machinery, enabling consistent, reliable product quality across all batches.
Mass Production & On-Time Shipment
Efficient full-scale manufacturing capacity ensures finished goods can be delivered within 15–20 working days, guaranteeing punctual shipment schedules.
ISO Standard Strict Quality Control
All production follows strict ISO 9001 standards. Each shipment carries a complete quality inspection certificate to satisfy factory release specifications.
Description
Pocket bag air filters are commonly used as secondary or final filters, positioned after a pleated filter. These filters, also known as bag filters or pocket filters, are available in five efficiency levels: 40-45%, 60-65%, 80-85%, 90-95%, and above 95%, corresponding to MERV 8, 11, 13, 14, and 15 ratings. The filter media is constructed from pieces sealed together to form pockets. Each pocket bag filter can have a specified number of pockets, such as 3-pocket or 6-pocket configurations, and the pocket lengths can vary. These combinations allow for various surface area sizes, where a larger surface area generally offers better Dust Holding Capacity (DHC) and longer filter service life.
- Large filtration area
- Low resistance
- Long service life
- High efficiency
- Large dust capacity
- Low power consumption
- Frame: Extruded aluminum, Galvanized steel
- Media: Meltblown PP
- Temperature: m≤70℃
- Humidity: ≤90%RH
Technical Parameters
| Product | Bag Filter |
| Medium material | Synthetic Fiber/ melt blown |
| 6 pockets(Customizable) | |
| Standard | According to EN779 standard |
| Dimension | Customizable |
| Range | F8 |
| Color | Yellow（customizable） |
| OEM | Welcome |
| Frame | Metal |
Standard Model Options
| Item | Specification |
|---|---|
| Product Name | Synthetic Fiber Pocket Bag Filter |
| Product Type | Medium Efficiency HVAC Bag Filter |
| Filter Grade | F8 |
| Filter Media | Synthetic Fiber + Melt-Blown PP |
| Frame Material | Metal / Aluminum / Galvanized Steel |
| Pocket Quantity | 6 Pockets (Customizable) |
| Standard | EN779 |
| Filter Color | Yellow (Customizable) |
| Operating Temperature | ≤70°C |
| Maximum Humidity | ≤90% RH |
| Installation | AHU / HVAC Systems |
| OEM / ODM | Supported |
| Supply Form | Finished Pocket Filter |
Applications
| Commercial HVAC | Industrial Air Filtration | Public Buildings | HEPA Pre-Filtration |
|---|---|---|---|
| Suitable for office buildings, shopping malls, hotels, airports, commercial HVAC units, and central air-conditioning systems. | Used in manufacturing plants, workshops, electronics factories, pharmaceutical production, and general industrial ventilation systems. | Installed in hospitals, schools, subway stations, exhibition centers, public buildings, and clean indoor environments requiring stable air quality. | Used as a medium-efficiency pre-filter to protect fine filters and HEPA filters, extending their service life and reducing operating costs. |
Customization & Quality Control
| Customization Available | Quality Inspection |
|---|---|
| • Custom dimensions and frame sizes • Aluminum, galvanized steel, stainless steel, or metal frames • Custom pocket quantity and depth • F6, F7, F8, and F9 efficiency options • Customized media colors and labeling • OEM logo and private packaging • Special airflow and pressure-drop configurations • Project-based engineering support |
• Incoming raw material inspection • Media basis weight and efficiency verification • Pocket stitching and welding inspection • Frame dimensional accuracy check • Air leakage and sealing test • Pressure drop and airflow performance testing • Final appearance and packaging inspection • Batch traceability and factory quality documentation |
