V-Bank Micro Fiberglass Merv 12 to Merv 16 Available HEPA Filter
V-Bank Micro Fiberglass Merv 12 to Merv 16 Available HEPA Filter
Features
- High-efficiency micro fiberglass filter media
- Available in MERV 12, MERV 13, MERV 14, MERV 15 and MERV 16
- V-bank design maximizes effective filtration area
- High airflow capacity with low operating resistance
- Excellent dust holding capacity for longer service life
- Uniform airflow distribution for stable filtration performance
- Lightweight and rigid construction
- Galvanized steel, aluminum, or plastic frame options
- Moisture-resistant and temperature-resistant design
- OEM & ODM manufacturing available
Fast Sampling Support
Samples ready within 3–7 days for custom OEM & ODM orders. Flexible customization solutions are available to match your unique product requirements.
Advanced Production Equipment & Stable Quality
Equipped with professional automated production lines and sophisticated testing machinery, enabling consistent, reliable product quality across all batches.
Mass Production & On-Time Shipment
Efficient full-scale manufacturing capacity ensures finished goods can be delivered within 15–20 working days, guaranteeing punctual shipment schedules.
ISO Standard Strict Quality Control
All production follows strict ISO 9001 standards. Each shipment carries a complete quality inspection certificate to satisfy factory release specifications.
Description
The V-Bank Micro Fiberglass HEPA Filter is engineered to provide high-efficiency particulate filtration in demanding HVAC and air handling systems. Its deep V-bank structure significantly increases the filtration surface area, allowing higher airflow volumes while maintaining a lower pressure drop than traditional box filters.
Manufactured using premium micro fiberglass media, the filter efficiently captures dust, pollen, mold spores, bacteria, smoke particles, and other fine airborne contaminants. The rigid frame construction ensures dimensional stability under continuous airflow, making it ideal for commercial and industrial environments requiring reliable air filtration.
Designed for energy-efficient operation, the filter combines high filtration performance with reduced operating costs and extended replacement intervals.
Technical Parameters
| Model | Size (mm) |
Carbon content (kg) |
Comprehensive adsorption Rate(%) |
CTC (%) |
Benzene (%) |
Deodorizing Performance (30mins) |
Frame material |
| ACVB7105CCFP-4V | 592*287*292-4V | 5 | >90% | >50% | >60% | >95% | Single flange plastic frame |
| ACVB8805CC-4V | 610*610*292-4V | 18 | >90% | >50% | >60% | >95% | Box |
| ACVB8205CC-4V | 610*305*292-4V | 9 | >90% | >50% | >60% | >95% | Box |
| ACVB2805CC-2V | 305*610*292-2V | 9 | >90% | >50% | >60% | >95% | Box |
| ACVB2205CC-2V | 305*305*292-2V | 4.5 | >90% | >50% | >60% | >95% | Box |
Standard Model Options
| Item | Description |
|---|---|
| Product Name | V-Bank Micro Fiberglass HEPA Air Filter |
| Filter Type | V-Bank High Efficiency Air Filter |
| Filter Media | Ultra-Fine Micro Fiberglass |
| Filter Efficiency | MERV 12–MERV 16 |
| Frame Material | Galvanized Steel / Aluminum / Plastic |
| Separator | Hot Melt Adhesive |
| Sealant | Polyurethane |
| Structure | Multi V-Bank |
| Filtration Function | Fine Particle Filtration |
| Installation | AHU / HVAC Systems |
| OEM / ODM | Available |
Applications
| Commercial HVAC Systems | Healthcare & Cleanrooms | Industrial Manufacturing | Public Buildings & Critical Facilities |
|---|---|---|---|
| Designed for office buildings, shopping malls, hotels, airports, schools, and commercial air handling units to improve indoor air quality and protect HVAC equipment. | Ideal for hospitals, pharmaceutical plants, laboratories, cleanrooms, and healthcare environments where high-efficiency particulate filtration is essential. | Suitable for electronics manufacturing, food processing, precision assembly, automotive production, and other industrial facilities requiring clean process air. | Widely used in data centers, museums, libraries, research institutions, exhibition centers, and transportation hubs to maintain stable, high-quality indoor air conditions. |
Customization & Quality Control
| Customization Services | Quality Assurance & Inspection |
|---|---|
| • Custom filter dimensions, depths, and V-bank configurations (2V, 4V, 5V) • MERV 12–MERV 16 filtration efficiency options • Galvanized steel, aluminum, or plastic frame selections • Custom airflow capacity and pressure drop optimization • Moisture-resistant and high-temperature media options • Gasket installation and sealing configuration customization • OEM logo printing and private label packaging • Export packaging and pallet customization • Production based on customer drawings or samples • Flexible OEM and bulk manufacturing services |
• Incoming inspection of fiberglass media and frame materials • Pleat spacing and V-bank assembly verification • Dimensional accuracy and frame strength inspection • Airflow and initial pressure drop testing • Filtration efficiency testing according to applicable standards (upon request) • Seal integrity and leakage inspection • Appearance and workmanship verification • Packaging integrity and product labeling inspection • Batch traceability throughout production • Final quality inspection before shipment |
