Synthetic F5-F8 Midium Efficiency Pocket Filter Media Bag Roll Air Filter Raw Material
Synthetic F5-F8 Midium Efficiency Pocket Filter Media Bag Roll Air Filter Raw Material
Features
Fast Sampling Support
Samples ready within 3–7 days for custom OEM & ODM orders. Flexible customization solutions are available to match your unique product requirements.
Advanced Production Equipment & Stable Quality
Equipped with professional automated production lines and sophisticated testing machinery, enabling consistent, reliable product quality across all batches.
Mass Production & On-Time Shipment
Efficient full-scale manufacturing capacity ensures finished goods can be delivered within 15–20 working days, guaranteeing punctual shipment schedules.
ISO Standard Strict Quality Control
All production follows strict ISO 9001 standards. Each shipment carries a complete quality inspection certificate to satisfy factory release specifications.
Filter bag media rolls for pocket air filters are specialized materials used in the construction of pocket filters, which are essential components of HVAC systems for air purification. These media rolls are designed to trap and hold particulates from the air, effectively preventing them from circulating within an indoor environment.
This filter bag media is a semi-finished product intended for pocket filter assembly. It can be easily cut to the required length to create pocket filters with multiple bags.
Bag filter media is made from synthetic non-woven fabric, which has three layers, The first crude fiber filter catch bigger dust in the air, the thin fiber filter catch smaller dust and the outer is protective layer.The excellent ultrasonically weld technology avoids the air flow leak caused by wind area, decreases the resistance and enlarges the dust volume.
FEATURES● Small resistance ● Made of 2/3/4 layers PP fabric+MB fabric +Non-woven fabric ● High dust holding capacity ● Uniform color according to EN779 distinguish ● Safe material ● non-toxic and odorless ● Color is customizable |
APPLICATIONSIt is widely used in all kinds of pocket filters, bag filters, prefilters for HVAC and ventilation systems. |
SPECIFICATIONS
| Type | Color | Filter Class | Size(mm) W*H*D | Pockets | Pressure Drop at Rated Airflow | |||||
| HF-WFD-F7 | Pink | F7/80-85% | Pa | m3/h | Pa | m3/h | Pa | m3/h | ||
| 595x595x600 | 8 | 45 | 2300 | 80 | 3500 | 110 | 4500 | |||
| 595x595x600 | 6 | 45 | 2100 | 80 | 3200 | 110 | 4300 | |||
| 495x595x600 | 6 | 45 | 2000 | 80 | 3000 | 110 | 4200 | |||
| 595x295x600 | 3 | 45 | 1100 | 80 | 1800 | 110 | 2300 | |||
