Premium Activated Carbon Roll Filter Material High – Efficiency Dust Removal for Air Purification
Premium Activated Carbon Roll Filter Material High – Efficiency Dust Removal for Air Purification
Features
Premium Activated Carbon Roll Filter Material: High – Efficiency Dust Removal for Air Purification. Engineered for superior air quality, our fiberglass air filter paper captures fine particles, ensuring clean air in residential and commercial settings.
- Open-cell activated carbon foam structure
- Large specific surface area
- Strong adsorption of formaldehyde, toluene, and selected gases
- High deodorization efficiency
- High dust-holding capacity
- Low initial airflow resistance
- Good chemical stability
- High mechanical strength
- Good formability and dimensional stability
- Suitable for air and selected water-treatment applications
- Available in multiple thicknesses
- Easy to cut, laminate, die-cut, and frame
- Custom roll width, length, carbon content, and thickness available
- OEM and ODM services supported
Fast Sampling Support
Samples ready within 3–7 days for custom OEM & ODM orders. Flexible customization solutions are available to match your unique product requirements.
Advanced Production Equipment & Stable Quality
Equipped with professional automated production lines and sophisticated testing machinery, enabling consistent, reliable product quality across all batches.
Mass Production & On-Time Shipment
Efficient full-scale manufacturing capacity ensures finished goods can be delivered within 15–20 working days, guaranteeing punctual shipment schedules.
ISO Standard Strict Quality Control
All production follows strict ISO 9001 standards. Each shipment carries a complete quality inspection certificate to satisfy factory release specifications.
Description
Enhance air quality with our Premium Activated Carbon Roll Filter Material, designed for high – efficiency dust removal. Made from high – quality fiberglass, this filter paper captures fine particles and contaminants, ensuring cleaner, healthier air. Ideal for residential and commercial air purification systems.
Rich pore structure and large specific surface area;
The strong adsorption capacity for harmful gases such as formaldehyde and toluene;
Good deodorizing effect;
Good chemical stability and high mechanical strength;
Good formability and low airflow resistance;
Small resistance and large dust holding capacity.
Technical Parameters
| Model | Size | Weight (g/m2) |
Carbon content (g/m2) |
I.N.P (Pa) |
F.N.P (Pa) |
Adsorption efficiency |
Deodorization performance (30 minutes) |
Dust holding capacity (g/m3) |
EFF. (≥5μm) |
| AC03SF | 1.25*50m*3mm | 180 | 90 | 25 | 250 | 90% | >95% | 300 | 90% |
| AC05SF | 1.12m*50m*5mm 1.18m*50m*5mm 1.28m*50m*5mm |
250 | 125 | 28 | 250 | 90% | >95% | 350 | 95% |
| 1.25m*50m*5mm | 300 | 150 | 30 | 250 | 90% | >95% | 500 | 95% | |
| AC10SF | 1.5m*30m*10mm 2m*30m*10mm |
400 | 200 | 35 | 250 | 95% | >95% | 580 | 95% |
| AC15SF | 1.5m*20m*15mm 2m*20m*15mm |
500 | 250 | 40 | 300 | 95% | >95% | 650 | 98% |
| AC20SF | 1.5m*20m*20mm 2m*20m*20mm |
600 | 300 | 45 | 300 | 98% | >95% | 750 | 99% |
Standard Model Options
| Item | Specification |
|---|---|
| Product Name | Activated Carbon Foam Filter Media Roll |
| Product Type | Carbon Sponge / Odor-Control Filter Media |
| Model Series | HF-AC |
| Base Material | Open-Cell Foam |
| Adsorbent | Activated Carbon |
| Standard Color | Black |
| Available Thicknesses | 3 / 5 / 10 / 15 / 20 mm |
| Carbon Content | 90–300 g/m² |
| Basis Weight | 180–600 g/m² |
| Initial Resistance | 25–45 Pa |
| Recommended Final Resistance | 250–300 Pa |
| Adsorption Efficiency | 90–98% |
| Deodorization Performance | >95% after 30 minutes |
| Dust-Holding Capacity | 300–750 g/m³ |
| Particle Efficiency | 90–99% for particles ≥5 μm |
| Supply Form | Roll / Sheet / Pad / Custom-Cut Part |
| OEM / ODM | Available |
Applications
| HVAC & Ventilation Systems | Air Purifiers & Commercial Interiors | Industrial Exhaust & Odor Control | Water and Specialty Filtration |
|---|---|---|---|
| Used in return-air filters, air-conditioning systems, ventilation units, and pre-filters for dust and odor reduction. | Suitable for household and commercial air purifiers, offices, hotels, schools, and retail spaces. | Applied in factories, workshops, coating areas, exhaust systems, and waste-gas treatment equipment for odor and VOC reduction. | Can be used in selected water-purification and custom adsorption applications after confirming media compatibility. |
Customization & Quality Control
| Customization Available | Quality Inspection |
|---|---|
| • Custom roll width and length • 3 / 5 / 10 / 15 / 20 mm thickness options • Custom activated carbon content • Custom basis weight and foam density • Roll, sheet, pad, disc, or irregular die-cut shapes • Laminated and adhesive-backed configurations • OEM labels, branding, and export packaging • Samples for airflow and adsorption trials |
• Foam pore structure and thickness inspection • Activated carbon content verification • Basis-weight and dimensional inspection • Surface uniformity and defect check • Initial resistance and airflow testing • Adsorption and deodorization testing upon request • Dust-holding and particle-efficiency testing • Final cutting, packaging, and appearance inspection |
