H13 H14 U15 Particulate Fiberglass Air Filter Paper HEPA Panel Filter Glass Fiber Media
H13 H14 U15 Particulate Fiberglass Air Filter Paper HEPA Panel Filter Glass Fiber Media
Features
H13, H14, U15 HEPA Panel Filters made with Glass Fiber Media for high-efficiency particulate filtration. Ideal for cleanrooms and critical environments.
- H13 and H14 HEPA filtration grades
- F6–F9 and H10–H12 grades also available
- Fine glass fiber filtration media
- High particle capture efficiency
- Low and controlled airflow resistance
- Uniform thickness and basis weight
- High tensile strength
- Excellent stiffness for stable pleating
- Suitable for mini-pleat and panel filter production
- Good dimensional stability during processing
- Compatible with pleating, slitting, cutting, and bonding
- Suitable for terminal filtration and cleanroom applications
- Custom roll width, length, and grade available
- OEM and ODM manufacturing supported
Fast Sampling Support
Samples ready within 3–7 days for custom OEM & ODM orders. Flexible customization solutions are available to match your unique product requirements.
Advanced Production Equipment & Stable Quality
Equipped with professional automated production lines and sophisticated testing machinery, enabling consistent, reliable product quality across all batches.
Mass Production & On-Time Shipment
Efficient full-scale manufacturing capacity ensures finished goods can be delivered within 15–20 working days, guaranteeing punctual shipment schedules.
ISO Standard Strict Quality Control
All production follows strict ISO 9001 standards. Each shipment carries a complete quality inspection certificate to satisfy factory release specifications.
Description
Our H13, H14, and U15 HEPA Panel Filters are designed with high-efficiency Glass Fiber Media to capture ultra-fine particulates. This Particulate Fiberglass Air Filter Paper ensures superior air quality, making it ideal for critical environments like cleanrooms and healthcare facilities.
-
High Efficiency: H13, H14, and U15 ratings for superior particulate capture.
-
Glass Fiber Media: Durable and effective for ultra-fine particle filtration.
-
HEPA Panel Design: Compact and easy to install in various systems.
Technical Parameters
| Class | Grade | Efficiency | Resistance | Tensile Strength | Thickness | Basic Weight | Stiffness |
| HEPA 0.3mm @5.3cm/s |
H14 | ≥99.995% | ≤420Pa | 1.0-1.25KN/m | 0.33±0.02mm | 74±4g/m2 | mg≥1000 |
| H13 | ≥99.97% | ≤330Pa | 0.9-1.20KN/m | 0.33±0.02mm | 74±4g/m2 | mg≥1000 | |
| H12 | ≥99.8% | ≤260Pa | 0.9-1.20KN/m | 0.33±0.02mm | 74±4g/m2 | mg≥1000 | |
| H11 | ≥98% | ≤180Pa | 0.9-1.20KN/m | 0.33±0.02mm | 74±4g/m2 | mg≥1000 | |
| H10 | ≥94% | ≤120Pa | 0.9-1.20KN/m | 0.33±0.02mm | 74±4g/m2 | mg≥1000 | |
| ASHRAE 0.4mm @5.3cm/s |
F9 | ≥95% | ≤80Pa | 0.9-1.15KN/m | 0.33±0.02mm | 70±4g/m2 | mg≥900 |
| F8 | ≥90% | ≤60Pa | 0.9-1.15KN/m | 0.33±0.02mm | 70±4g/m2 | mg≥900 | |
| F7 | ≥80% | ≤40Pa | 0.9-1.15KN/m | 0.33±0.02mm | 70±4g/m2 | mg≥900 | |
| F6 | ≥60% | ≤25Pa | 0.9-1.15KN/m | 0.33±0.02mm | 70±4g/m2 | mg≥900 |
Standard Model Options
| Item | Specification |
|---|---|
| Product Name | Fiberglass HEPA Filter Paper Roll |
| Product Type | HEPA / Fine Air Filter Raw Material |
| Model Series | HF |
| Filter Media | Fine Glass Fiber Paper |
| Available Grades | F6 / F7 / F8 / F9 / H10 / H11 / H12 / H13 / H14 |
| Main HEPA Grades | H13 / H14 |
| Reference Particle Size | 0.3 μm for HEPA Grades |
| Standard Thickness | 0.33 ± 0.02 mm |
| Basis Weight | 70 ± 4 or 74 ± 4 g/m² |
| Tensile Strength | 0.9–1.25 kN/m, Depending on Grade |
| Stiffness | ≥900–1000 mg |
| Supply Form | Roll Media |
| Standard Color | White |
| Main Use | Panel, Mini-Pleat and Terminal Filter Manufacturing |
| OEM / ODM | Available |
Applications
| Cleanrooms & Pharmaceutical Facilities | Healthcare & Laboratories | HVAC & Commercial Filtration | Electronics & Precision Manufacturing |
|---|---|---|---|
| Used in terminal HEPA filters, FFUs, ceiling modules, sterile rooms, and pharmaceutical production areas. | Suitable for hospitals, operating rooms, isolation rooms, laboratories, clean benches, and medical air systems. | Used in high-efficiency panel filters, mini-pleat filters, AHUs, and commercial or industrial ventilation systems. | Applied in semiconductor, electronics, optics, battery, aerospace, and other contamination-sensitive production environments. |
Customization & Quality Control
| Customization Available | Quality Inspection |
|---|---|
| • Custom roll width and roll length • F6–H14 filtration-grade options • Custom resistance and efficiency targets • Custom basis weight and thickness • Pleating-stiffness optimization • Custom slitting and roll-core dimensions • Media for mini-pleat, panel, separator, and terminal filters • OEM labels, private branding, samples, and export packaging |
• Fiberglass raw-material verification • Roll width, length, and thickness inspection • Basis-weight and media-uniformity testing • Tensile-strength and stiffness inspection • Surface defect and fiber-distribution check • Airflow-resistance testing • Particle-filtration efficiency testing under agreed conditions • Final roll winding, batch identification, and packaging inspection |
