Heavy-Duty [Specific Inch] V Bank Air Filter Frame - Durable Steel Construction for Industrial HVAC & Automotive Filtration Systems06

Heavy-Duty [Specific Inch] V Bank Air Filter Frame - Durable Steel Construction for Industrial HVAC & Automotive Filtration Systems01

Heavy-Duty [Specific Inch] V Bank Air Filter Frame – Durable Steel Construction for Industrial HVAC & Automotive Filtration Systems

Features

Designed for 4V compact and V-bank air filters
ABS or PVC engineering plastic construction
Reinforced structure for stable filter-pack support
Lightweight compared with conventional metal frames
Good corrosion and moisture resistance
Suitable for turbulent and high-volume airflow
Four-V configuration increases available media area
Helps maintain accurate filter-pack positioning
Compatible with synthetic and fiberglass filter media
20 mm and 25 mm header options
Easy assembly and disassembly
No exposed metal components in standard configurations
Black, blue, white and custom colors available
Standard and customized dimensions supported
OEM mold development and bulk production available

Chat Now

Message

Fast Sampling Support

Samples ready within 3–7 days for custom OEM & ODM orders. Flexible customization solutions are available to match your unique product requirements.

Advanced Production Equipment & Stable Quality

Equipped with professional automated production lines and sophisticated testing machinery, enabling consistent, reliable product quality across all batches.

Mass Production & On-Time Shipment

Efficient full-scale manufacturing capacity ensures finished goods can be delivered within 15–20 working days, guaranteeing punctual shipment schedules.

ISO Standard Strict Quality Control

All production follows strict ISO 9001 standards. Each shipment carries a complete quality inspection certificate to satisfy factory release specifications.

Description

The Reinforced 4V Filter Frame is designed for the production and assembly of compact V-bank air filters used in commercial HVAC systems, industrial air-handling units, cleanrooms and equipment ventilation applications.

Manufactured from durable ABS or PVC engineering plastic, the frame combines high structural strength with low weight, corrosion resistance and easy assembly. Its four-V configuration securely supports multiple pleated filter packs while maximizing the effective filtration area within a compact installation depth.

Standard models are available in 592 × 592 × 292 mm, with 20 mm or 25 mm header options. Dimensions, color, structural details and assembly interfaces can be customized for OEM filter manufacturers and project-specific filtration systems.

Technical Parameters

Color	Black /Blue /White
Size	592592292mm or customized
Material	ABS /PVC Plastic
Header	25mm or 20mm
Max. temperature	85
Max. humidity	80%RH

Standard Model Options

Item	Description
Product Name	4V V-Bank Filter Frame
Product Type	Compact Air Filter Manufacturing Component
Structure	Four-V / V-Cell
Standard Material	ABS / PVC Engineering Plastic
Standard Color	Black / Blue / White
Custom Color	Available
Standard Size	592 × 592 × 292 mm
Header Options	20 mm / 25 mm
Main Function	Supporting and Positioning Filter Media Packs
Applicable Filter Type	Compact V-Bank / V-Cell Air Filter
Maximum Temperature	85°C
Maximum Relative Humidity	80% RH
Assembly Method	Mechanical Assembly / Project-Specific Fixing
Reusability	Depending on Final Filter Construction
Customization	Available
OEM / ODM	Supported

Applications

Commercial HVAC Systems	Industrial Air-Handling Units	Cleanroom & Controlled Environments	OEM Filter Manufacturing
Used as the structural frame for compact V-bank filters installed in offices, hotels, shopping centers and public-building AHUs.	Suitable for factories, warehouses and process ventilation systems requiring high airflow and compact filtration assemblies.	Supports medium- and high-efficiency filters used in pharmaceutical, electronics, laboratory and clean-process applications.	Supplied to air-filter manufacturers producing standard or proprietary 4V compact filters for global replacement markets.

Customization & Quality Control

Customization Available	Quality Inspection
• Custom overall width, height and depth • ABS or PVC material selection • Custom resin grade upon request • 20 mm, 25 mm or custom header • Custom internal V angle and spacing • Structural reinforcement design • Black, blue, white or custom colors • Compatibility with customer media packs • Mold development from drawings or samples • Embossed logo and molded identification • Custom labels, cartons and pallet packaging • Bulk OEM production	• Incoming resin material inspection • Color and material consistency verification • Injection-molding parameter control • Overall dimension and tolerance inspection • Header height verification • Flatness and frame-squareness inspection • Internal V spacing measurement • Structural-strength testing • Assembly compatibility inspection • Surface inspection for cracks, flash or deformation • Packaging and quantity verification • Batch identification and traceability
